MINI 1 the small machine for ticket's reading
NEW MODEL *
- MULTISCAN MINI 1 reads barcoded documents with total accuracy.
- MULTISCAN MINI 1 works stand alone.
- MULTISCAN MINI 1 is compact, portable, silent, easy to install, operate and maintain and it can process different types of documents.
- MULTISCAN MINI 1 is a reliable machine due to its sturdy construction and excellent components.
Technical
- Reading speed Up to 120 documents per minute.
- Autonomy The unit works as a smart peripheral, it does not need a PC for operation or configuration. Data can be transmitted to any host through an RS232C in stream.
- High Data Capture Capacity
It reads any of the following
codes: All UPC / EAN / JAN, Code39, Code128,
I2of5 and Codabar/NW7
- Capacity Input tray capacity: 40 docs. (0.1 mm paper thickness)
Output tray capacity: 40 documents
- Host communication Type: RS232C
- Supply voltage 110/220v,50/60Hz
Barcode
Symbologies
- 1D
- Readable symbologies: All UPC / EAN / JAN,
Code39, Code128, I2of5 and Codabar/NW7
- Location: in horizontal position, from 3 mm
to 22 mm measured from the bottom of the paper.
- Minimum code height: 0.2" (5 mm)
- Maximum code density: 10 mils.
Dimensions
- Height: 5.9" (152mm)
- Width: 5.5" (142mm)
- Depth: 11.4" (291 mm)
- Weight: 1500 gr. (without the adapter)
Documents Size
- Length from 2.8"(72 mm) to 7.5" (190 mm)
- Height from 2.3"(58 mm) to 4.7"(120 mm)
- Paper Thickness: 60 up to 120 gr/m2
