Multiscan MT31r

MT31R Automatic Barcoded Document Reader
NEW MODEL *

Automatic stop with full stacker and automatic restart when it is emptied. Documents processed are neatly stacked in the same order they are fed. Great productivity increase compared to previous models.

MULTISCAN MT31R reads large volumes of barcoded documents at high speed and with total accuracy using laser technology. MULTISCAN MT31 R works stand alone.

MULTISCAN MT31R is compact, portable, silent, easy to install, operate and maintain and it can process different types of documents.

MULTISCAN MT31R is a reliable machine due to its sturdy construction and excellent components.

Nowadays, there are thousands of Multiscan machines working with different applications in more than 60 countries all around the world.

Technical
  • Reading speedUp to 1100 documents per minute for the smallest documents.
  • Speed SelectionThe operator can select the most suitable speed for each application from the keypad at any moment.
  • Automatic DiscardDefective documents, either damaged, illegible or strange are automatically sent to a discard bin.
  • Manual OperationData and document batch header can be manually operated by means of the keypad.
  • Double DetectionIt can detect double feedings and transparency variations amount documents.
  • Host CommandConfiguration, start, stop and other functions can be commanded from the host.
  • Multiple ReadingIt can read up to 6 linear codes on the same document.
  • AutonomyThe unit works as a smart peripheral, it does not need a PC for operation or configuration. Data can be transmitted to any host through an RS232C in stream or batch mode.
  • High Data Capture CapacityIt reads up to 62 characters per line in any of the following codes: Code 128, I 2/5, C39, Codabar, UPC and EAN. It can also read C93 (optional).
  • Different code readingIt reads documents with different types of codes and/or length within the same batch.
  • VFD displayThe display shows operating data, configuration and status making it easy to operate the equipment.
  • PasswordAccess to the unit configuration can be password restricted.
  • Count ModeIt can count documents, banknotes or any other document without barcodes on it.
  • Addition and SortingApart from reading, the unit can add, sort and/or discard documents based on a certain field of the barcode of each document (date, branch, type, number, etc.)
  • CapacityInput tray capacity: 70mm Output trays capacity: 250 docs. (accepted), 250 docs. (rejected)
  • Host communicationType: RS232C
  • Supply voltage120+10% VAC , 50/60Hz
Barcode
Symbologies
  • 1D barcode 1d
  • 2D barcode 2d
  • Readable symbologies: Code 39, Code 128, I 2/5, Codabar, UPC/EAN (standard symbologies), C93 (optional)
  • Readable characters: 62 chars./code
  • Maximum code length: 4.5" (114 mm)
  • Minimum code height: 1/2" (12 mm)
  • Maximum code density: 10 mils.
Dimensions
  • Height: 18.9" (480 mm)
  • Width: 18.5" (469 mm)
  • Depth: 18" (457 mm)
  • Weight: 41.9 lbs (19 Kg.)
  • Footprint: 10.2" (260 mm) [width]x 9" (230 mm) [depth].
Documents Size
  • Minimum size 2.25"(57 mm) x 2"(51 mm)
  • Maximum size 8.5" (216 mm) x 4"(101 mm)
  • Paper Thickness: 80 up to 140 gr/m2
